Technology Cover

2023-02-01, Analog Devices dual-wide range power monitor

The LTC2992 is a rail-to-rail system monitor that measures current, voltage, and power of two supplies. It features an operating range of 2.7V to 100V and includes a shunt regulator for supplies above 100V.

Technology Cover

2023-02-01, Texas Instruments 3-axis - +/-2g ultracompact linear accelerometer

The LIS3L02AL is a low-power 3-axis linear capacitive accelerometer that includes a sensing element and an IC interface able to take the information from the sensing element and to provide an analog signal to the external world

Technology Cover

2023-02-01, Multi-core fixed and floating-point digital signal processors

The TMS320C6678 DSP is a highest-performance fixed/floating-point DSP that is based on TI's KeyStone multicore architecture. Incorporating the new and innovative C66x DSP core, this device can run at a core speed of up to 1.4 GHz.

Technology Cover

2023-02-01, Microchip unveiled a new all-in-one hybrid drive module designed for electric aviation applications

Microchip Technology announced the launch of a new integrated hybrid drive module, the first model in a new line of power devices. The line of products will come in 12 different models using silicon carbide (SiC) mosFETs or insulated gate bipolar transistors (IGBTs).

Technology Cover

2023-01-14, Step-down synchronous rectifier pulse width modulator (PWM) controller

The ISL6522 provides complete control and protection for a DC-DC converter optimized for high-performance microprocessor applications. It is designed to drive two N-Channel MOSFETs in a synchronous rectified buck topology. The ISL6522 integrates all of the control, output adjustment, monitoring and protection functions into a single package.

Technology Cover

2023-01-14, Low drive GTLP/LVTTL 1:6 clock drive

The GTLP6C817 is a low drive clock driver that provides TTL to GTLP signal level translation (and vice versa). The device provides a high speed interface between cards operating at TTL logic levels and a backplane operating at GTLP logic levels. High speed backplane operation is a direct result of GTLP’s reduced output swing (<1V), reduced input threshold levels and output edge rate control.

Technology Cover

2023-01-14, 103-dB, 192-kHz, stereo audio ADC with 6:1 input Mux

The CS5346 integrates an analog multiplexer, programmable gain amplifier, and stereo audio analog-to-digital converter. The CS5346 performs stereo analog-to-digital (A/D) conve rsion of 24-bit serial values at sa mple rates up to 192 kHz.

Technology Cover

2023-01-14, Renesas Low Noise 24-bit Delta Sigma ADC

The ISL26102 and ISL26104 provide a low-noise programmable gain amplifier along with a 24-bit Delta-Sigma Analog-to-Digital Converter with two channel (ISL26102) or four channel (ISL26104) differential, multiplexed inputs. The devices feature exceptional noise performance for conversion rates ranging from 2.5Sps to 4kSps

Technology Cover

2023-01-14, Intersil offers General Purpose Timers

The ICM7555 and ICM7556 are CMOS RC timers providing significantly improved performance over the standard SE/NE 555/556 and 355 timers, while at the same time being direct replacements for those devices in most applications. Improved parameters include low supply current, wide operating supply voltage range, low Threshold, Trigger and Reset currents, no crowbarring of the supply current during output transitions, higher frequency performance and no requirement to decouple Control Voltage for stable operation.

Technology Cover

2023-01-14, High performance, 14 bit, low power micro CMOS ADC

The TLC3541 and TLC3545 are a family of high performance, 14-bit, low power, miniature CMOS analog-to-digital converters (ADCs). These devices operate from a single 5-V supply. Devices are available with single, dual, or single pseudo-differential inputs. All of these devices have a chip select (CS), serial clock (SCLK), and serial data output (SDO) that provides a direct 3-wire interface to the serial port of most popular host microprocessors (SPI interface).

Technology Cover

2023-01-13, 14-bit non-contact digital Angle sensor with ABZ and UVW incremental output

The MA330 detects the absolute angular position of a permanent magnet (usually a radially magnetized cylindrical permanent magnet) on the axis of rotation. Its fast data acquisition and processing capabilities provide accurate Angle measurements at 0-60,000 RPM. In servo applications, the performance of the control loop can be optimized by adjusting the digital filter

Technology Cover

2023-01-13, Vishay introduces new electronic fuses with adjustable current limits and overvoltage protection

Vishay Intertechnology has announced the launch of four new electronic fuses in small 3 mm x 3 mm TDFN packages with adjustable current Limit and overvoltage Protection (OVP) features -SiP32433A/B and SiP32434A/B. 3.5 A SiP32433A/B and 6 A SiP32434A/B operate in the input voltage range of 2.8V to 23 V -- up to 28 VIN DC -- integrating multiple control and protection functions, simplifying the design and reducing the need for external components

Technology Cover

2023-01-13, Minimum TEC optical module power driver

The MAX8520/MAX8521 are designed to drive thermoelectric coolers (TECs) in space-constrained optical modules. Both devices deliver ±1.5A output current and control the TEC current to eliminate harmful current surges. On-chip FETs minimize external components and high switching frequency reduces the size of external components

Technology Cover

2023-01-13, 1.5MHz, 800mA dual output synchronous step-down converter

The MP2102 is a dual-output, internally compensated, 1.5MHz fixed frequency PWM step-down converter. It is ideal for powering portable equipment from a single cell LithiumIon (Li+) Battery. Each channel of the MP2102 can supply 800mA of load current from a 2.5V to 6V input voltage. Both output voltages can be regulated as low as 0.6V

Technology Cover

2023-01-13, Texas Instruments high performance current mode PWM controller

The TL284xB and TL384xB series of control integrated circuits provide the features that are necessary to implement off-line or dc-to-dc fixed-frequency current-mode control schemes, with a minimum number of external components. Internally implemented circuits include an undervoltage lockout (UVLO) and a precision reference that is trimmed for accuracy at the error amplifier input.

Technology Cover

2023-01-13, Microchip Technology single chip OOK receiver

The MICRF001 is a single chip OOK (ON-OFF Keyed) Receiver IC for remote wireless applications, employing Micrel’s latest QwikRadiotm technology. This device is a true “antenna-in, dataout” monolithic device. All RF and IF tuning is accomplished automatically within the IC, which eliminates manual tuning, and reduces production costs
